2 Core 12V Flat Automotive Cable

2 Core 0.5mm²-4.5mm² Twin Core Automotive Cable 12V/24V - Available in 5-100m Lengths

High-quality thin wall low voltage twin core cable ideal for automotive, marine, and industrial applications. Features a durable black outer sheath with red and black inner cores, engineered for optimal performance in demanding environments. Resistant to automotive fluids including petrol, diesel, oils, and diluted acids. This professional-grade automotive cable offers excellent current ratings and space efficiency.

Technical Specifications:

• Cross Sections: 0.5mm², 0.75mm², 1.0mm², 1.5mm², 2.0mm², 2.5mm², 3.0mm², 4.5mm²
• Current Rating: 11-42 Amps (size dependent)
• Maximum Operating Temperature: 105°C
• Note: Size measurements (²) indicate copper cross-sectional area

Superior Construction:

• Insulation: Calcium Zinc compound (ISO6722-2011 Class B)
• Thermal Stability: 200 minutes at 200°C
• Sheath: Easy-strip PVC (BS7655 Type 6)

• Core Colors: Red/Black

Applications

• Automotive electrical systems
• Marine installations
• Industrial equipment
• Low voltage power distribution
• Vehicle modifications
• Mobile equipment

Trade & Bulk Orders:

For B2B inquiries and volume pricing, please contact our sales team:
Email: sales@mkgt.co.uk
Chat: Available during business hours
Custom lengths and specifications available
